38" x 120" KENT USA HL-37 SERIES MANUAL PRECISION LATHE - NEW

Manufacturer

KENT

Model

HL-37

Year

Not provided

Stock #

12788

Condition

New

Request A Quote

Keep Scrolling To Learn More

Specifications

Equipped With

38" x 120" KENT USA HL-37 SERIES MANUAL PRECISION LATHE - NEW

PRODUCT HIGHLIGHTS

  • 20 HP Spindle Motor, 16-Speeds
  • 5.98” Spindle Through Hole
  • Extra Heavy Ribbed One Piece Bedways and Base
  • Spindle Jog Button Control
  • One-shot Lubrication for Apron, Carriage, and Bed Ways
  • Two Speed Tailstock
  • Magnetic Clutch Brake
  • 4 Way Rapid Feed



STANDARD ACCESSORIES
  • Steady rest
  • Work light
  • Thread chasing dial
  • Follow rest
  • 4-position tool post
  • Coolant system



OPTIONAL ACCESSORIES

  • Digital Readout System
  • Chuck cover
  • 3-jaw chuck (20″)
  • 4-jaw independent chuck (32″ or 40″)
  • 9″ / 12″ spindle bore
  • Face plate
  • Royal spindle type live center
  • Taper turning attachment
  • Rear of spindle chuck adapter plate for 32″ 4-jaw chuck
  • BTC 3-jaw chuck with back plate
  • Micrometer carriage stop
  • Rustlick coolant






  • Swing Over Bed
  • Swing Over Cross Slide
  • Swing Over Gap
  • Width of Bed
  • Distance Between Centers
  • Cross Slide Travel
  • Top Slide Travel
  • Spindle Speeds
  • Spindle Speed Range
  • Through Hole Diameter
  • Spindle Nose
  • Spindle Bore Taper
  • Thread – Standard (Whit-worth)
  • Thread – Metric Pitch
  • Longitudinal Feed
  • Cross Feed
  • Lead Screw Diameter
  • Threading Pitch
  • Quill Travel
  • Quill Diameter
  • Quill Bore Taper
  • Main Motor
  • Coolant Pump Motor
  • Machine Dimension
  • Packing Dimension
  • Machine weight
  • Packing weight
  • HL-37 Series

  • 37.8"
  • 14.2"
  • 54-3/8"
  • 24"
  • 120" (Opt 80" / 160" / 200" / 240" / 280" / 320")
  • 23.6"
  • 13.78"
  • 16
  • 4-420 RPM
  • 5.98"
  • ASA A2-11
  • NA
  • 1/4 - 30 TPI
  • 1-120 mm
  • 0.00236" - 0.0277" IPM
  • .00118 - .00138"
  • NA
  • NA
  • 12"
  • 4.5"
  • MT#6
  • 20 HP
  • 1/8 HP
  • NA
  • 200" x 61" x 66"
  • NA
  • NA
