KNUTH ABS 320 B FULL AUTOMATIC HORIZONTAL BAND SAW
Year
Not provided
Stock #
16306
Condition
New
Keep Scrolling To Learn More
Specifications
Equipped With
| Roller guide length | 47 in |
| Feed rollers | 6 positions |
| Cutting capacity 90¡ round | 13 in |
| Cutting capacity 90¡ - square | 12 in |
| Cutting capacity 90¡ - flat | 13x8 in |
| Stop length | 20 in |
| Cutting speed | 65.4 - 327 fpm |
| Accuracy of the feeding | 0.02 in |
| Motor rating main drive | 3 Hp |
| Motor rating hydraulic pump | 0.5 Hp |
| Motor rating coolant pump | 0.2 Hp |
| Motor rating feed | 0.3 Hp |
| Blade dimensions | 144.09x1.06x0.04 in |
| Overall dimensions (length x width x height) | 73x34x50 in |
| Weight | 1,452 lbs |
| Part No. | 152755 |
- Saw frame and machine bed are made of premium cast-iron for torsion-free performance even under maximum loads
- New helical gears ensure above-average service life and low maintenance
- Infinitely variable saw frame feed
- Large size hydraulic cylinder for constant quiet operation
- Automatic adjustment of cutting height
- A bundle vise is provided for cutting entire material packs to length
- automatic band break control
- bundle vise
- coolant system
- operating tools
- operating tools
- saw-band
- chip wiper
- feed roller table 47"
- operator instructions
- operator manual
