FPK 4.2 - FPK 6.2


Not provided

Stock #




Request A Quote

Keep Scrolling To Learn More


Equipped With

  FPK 4.2FPK 6.2
Working Area
Table dimensions15x33 in20x37 in
Vertical table10x35 in12x49 in
Table load capacity (max.)550 lbs660 lbs
Slots (number/width/spacing)0.2x0.55x2.48 in0.28x0.55x2.48 in
T-slots, vertical table (number x width x spacing)0.12x0.55x2.48 in
Travel X-axis16.5 in23.6 in
Travel Y-axis9 in20 in
Travel Z-axis15 in16 in
Vertical Milling Spindle
Travel pinole4 in
Spindle center - column (min.)11 in6 in
Spindle center - column (max.)19 in26 in
Rapid Feed
Rapid Feed X-axis23.62 in/min
Rapid Feed Y-axis23.62 in/min
Rapid Feed Z-axis23.62 in/min
Work feed X-axis1 - 47 in/min1 - 24 in/min
Work feed Y-axis1 - 47 in/min1 - 24 in/min
Work feed Z-axis1 - 47 in/min1 - 24 in/min
Horizontal Milling Spindle / Vertical Milling Spindle
Speed range(12) 50 - 2,600 rpm(18) 90 - 3,200 rpm
Spindle mountISO 40
Drive Capacity
Motor rating main drive3 Hp5 Hp
Motor rating coolant pump0.1 Hp
Measures and Weights
Overall dimensions (length x width x height)48x52x71 in60x71x77 in
Weight2,596 lbs3,190 lbs

  • Machine column made of premium cast-iron, ensures maximum dynamic rigidity and constant precision
  • The FPK 6 features rigid box ways in the Z-axis, while X- and Y-axes are equipped with micro-adjustable dovetail guides
  • All guides are hardened and precision-ground
  • Precise preloaded ball screws on all axes
  • Ergonomically arranged controls and a swivelling control panel plus standard digital position indicator for maximum operator comfort
  • Both machines feature rigid outer arbor supports for horizontal milling
  • Large work tables and long travels of this compact machine allow a wide range of applications
  • Automatic feed on all axes, infinitely variable, with fast rapid feed
  • The vertical cutter head swivels, and the quill can be moved manually
  • The fine-tuned main spindle drive offers a wide speed range with high torque
  • An optional air-driven tool drawing system allows quick tool changes
  • Extensive accessory package included
  • Central lubrication system is standard equipment
  • The price includes a fully assembled 3-axis position indicator

3-axis position indicator, X.pos 3.1

  • Completely assembled, ready for operation and exact measurements
  • Lower error rate
  • Increased productivity
  • More accuracy
  • Resulting in valuable time savings
  • For increased productivity
  • Operator-specific features
  • Easy to read display
  • Resolution: 0.0004 / 0.0002"
  • Convenient keyboard layout
  • Axis position is maintained when display is turned off
  • Default coordinates
  • Hole circle pattern calculation
  • Calculator function
  • Radius / diameter toggle
  • Mm/inch conversion
  • Easy expansion and maintenance-free operation
  • Storage for 99 tools

  • 3-axis position indicator
  • central lubrication
  • reducing sleeves MT1, MT2, MT3
  • adapter ISO 40 / MT 3
  • cutter arbor, long, 1.06 inch
  • preloaded ball screws
  • stainless steel guideway cover Z- axis
  • chip tray
  • coolant system
  • LED work lamp
  • pull rod (M16) for horizontal / vertical
  • Level pads and bolts
  • operating tools
  • operator manual
