NEW 18 GAUGE PITTSBURGH MODEL PL-18E LOCKFORMER

Type

Roll Formers

Manufacturer

GMC

Model

PL-18E

Year

Not provided

Stock #

19098

Condition

New

Request A Quote

Keep Scrolling To Learn More

NEW 18 GAUGE PITTSBURGH MODEL PL-18E LOCKFORMER

Specifications

Equipped With

NEW 18 GAUGE PITTSBURGH MODEL PL-18E LOCKFORMER

ISO 9001 certified
4HP Heavy Duty AC main motor, 220V, 3 phase
Heavy welded all steel construction for maximum rigidity
It’s a Triplex, standard rolls include S & Drive (Slip & Drive Cleat), Drive Cleat, Double Seam, Pittsburgh Lock, Power Flanger, 5 in 1, all rolls are installed.
Heavy welded all steel construction for maximum rigidity
ACME side can be operated at same time
One year warranty for parts

STANDARD EQUIPMENT

Standard Pittsburgh Attachment # PA-18E, installed
Slip & Drive Roll (S & Drive)# SDR-18E , installed
Drive Cleat Roll # DCR-18E, installed
Double Seam Roll # DSR-18E, installed
Power Flanger # PF-18E, installed

OPTIONAL EQUIPMENT
Right Angle Roll # RAR-18E, ¼” | 3/8” & ½” - $995.00

Capacity: Pittsburgh Lock	26 Ga. - 18 Ga.
S Drive Lock	26 Ga. - 22 Ga.
Right Angle Lock	26 Ga. - 18 Ga.
Drive Cleat Lock	26 Ga. - 22 Ga.
Double Seam Lock	26 Ga. - 18 Ga.
Power Flange 1/4:	26 Ga. - 18 Ga.
Depth of Pocket	1/2"
Feeding Speed	23 FPM
Main Motor	4 HP, 3 Phase 15 AMP Prewired: 220VAC
Weight Approx	998 LBS
Machine Dimensions (LxWxH): Shipping Dimensions:	60"x26"x46" 63"x27"x48"

Attachments

There are no files attached to this listing currently. If you Have any further questions regarding this listing, please contact us for more information.
