NEW 4' X 1/4" GMC MODEL HBR-0425 PLATE ROLLING MACHINE

Manufacturer

GMC

Model

HBR-0425

Year

Not provided

Stock #

19150

Condition

New

Request A Quote

Keep Scrolling To Learn More

Specifications

Equipped With

NEW 4' X 1/4" GMC MODEL HBR-0425 PLATE ROLLING MACHINE

  • ISO 9001 certified
  • Taiwan Machines
  • All three rollers are driven
  • All three rollers are hardened, up to 50-52 HRC
  • Easy swing –out top roller
  • Standard cone attachment installed
  • 1 each LED indicator for bending roll position
  • Safety line all around the machine for emergency stop
  • Heavy Duty all steel welded machine construction
  • German Hydraulic logic system centrally located and quiet
  • Bending roll is hydraulic powered up/down & tilting adjustment
  • Planetary reduction gear and pump
  • All three rolls are made of high grade alloy steel
  • All rolls run forward and reverse  Safety type foot pedal control
  • Overload protection and disconnect switch
  • Power source 208V/220V, (Option 460 V , 3 phase)
  • One year industrial warranty for parts


STANDARD EQUIPMENT
  • LED indicator for bending roll position
  • Safety line all around the machine for emergency stop
  • Removable safety foot pedal and tool box
  • Cone attachment (to make cone parts)
  • (3) grooves 3/8”, ½”, 5/8” on roll for bending wire


OPTIONAL EQUIPMENT
Safety fence for enclosure of the back side of the machine -  $1,150.00


Roll Capacity:

Mild Steel

4' x 1/4"
Stainless Steel 4' x 3/16"
Min. Roll dia. 8"
Rolls Length 4' 3"
Rolls Dia.  6"
Pre-bend 0.18"
Rolls speed 5 RPM
Rolls Opening 2 1/2"
Oil Tank Cap. 45L = 12 Gal.
Main Motor 3 HP
Weigth 4,650 lbs.
Dimensions 87" x 36" x 53"

Attachments

There are no files attached to this listing currently. If you Have any further questions regarding this listing, please contact us for more information.
