KNUTH "Plasma-Jet TrueCut" PLASMA CUTTING MACHINE
Year
Not provided
Stock #
16194
Condition
New
Keep Scrolling To Learn More
Specifications
Equipped With
| Plasma-Jet TrueCut 1530 H | Plasma-Jet TrueCut 2040 H | Plasma-Jet TrueCut 3060 H | |
|---|---|---|---|
| Working Area | |||
| Cutting Width | 59 in | 79 in | 118 in |
| Cutting length | 118 in | 157 in | 236 in |
| Table height | 28 in | ||
| Table load capacity | 106 lbs/ft? | ||
| Rapid feed | 709 in/min | ||
| Weight (without plasma source) | 6,820 lbs | 9,020 lbs | 20,900 lbs |
- Stand-alone cutter table features rigid steel construction for high load capacity
- Stand-alone table eliminates thermal and mechanical influences on the plasma cutter system
- Dual-drive bridge
- High-quality linear guides on all axes
- Dynamic AC servo drives on all axes with maintenance-free, zero-backlash planetary gears
- Low-wear and low-maintenance helical gears are designed for continuous operation
- Automatic torch height control
- quick-coupling for cutter head allows quick head exchanges for reduced tooling time
- available with 5-axis cutter head, tube cutter, and many more options
- Optimum bed speed even for fine contours and tight radii
- Use the existing cutting parameters stored in the control to find the optimum cut
- table is prepared for filter system (automatic closure control)
- panasonic servo-motors and drives
- automatic torch height control with Hypertherm THC sensor
- cutter torch with magnetic coupling and crash sensor
- hypertherm Edge Connect CNC Unit
- 19Ó Touchscreen von ELO
- ethercat-E
- laser pointer
- Libellula.WIZARD PRO
- libellula.CAD 2D
