KNUTH SBS HORIZONTAL BAND SAW
Year
Not provided
Stock #
16118
Condition
New
Keep Scrolling To Learn More
Specifications
Equipped With
| SBS 255 | SBS 355 | |
|---|---|---|
| Cutting Capacities | ||
| Cutting capacity 90¡ round | 10 in | 14 in |
| Cutting capacity 90¡ - square | 9 in | 12 in |
| Cutting capacity 90¡ - flat | 12x9 in | 12x21 in |
| Cutting capacity 45¡ (square) L | 6 in | 11 in |
| Cutting capacity 45¡ (flat) L | 6x6 in | 11x11 in |
| Cutting capacity 45¡ (round) L | 6 in | 12 in |
| Cutting capacity 45¡ (square) R | 8 in | 11 in |
| Cutting capacity 45¡ (round) R | 8 in | 14 in |
| Cutting capacity 45¡ (flat) R | 8x9 in | 11x14 in |
| Cutting capacity 60¡ R (round) | 5 in | 9 in |
| Cutting capacity 60¡ R (square) | 5 in | 7 in |
| Cutting capacity 60¡ R (flat) | 5x6 in | 7x9 in |
| Cutting speed | 1772 / 3543 fpm | 787 / 3150 fpm |
| Drive Capacity | ||
| Motor rating main drive | 2 Hp | 3 Hp |
| Measures and Weights | ||
| Overall dimensions (length x width x height) | 68x29x45 in | 86x39x45 in |
| Weight | 836 lbs | 1,771 lbs |
- Rigid vise with lateral slide, long stroke and long guideways in the movable jaw segments
- Hydraulic quick-action clamping fixture with proven performance in series production ensures constant tension to the last cut
- Infinitely variable saw blade speed for optimum machining of a wide range of materials and profiles
- Easy handling - at the end of the cut, the integrated hydraulics lift the saw frame to the home position
- The one-piece cast-iron saw frame is torsion-proof and swivels 60¡ to the right, and 45¡ to the left
- Rigid saw blade guides offer a wide adjustment range for workpieces with small and large cross-sections
- The combination of carbide jaws and adjustable ball bearing guides ensure precision cuts
- A wide bi-metallic saw blade ensures additional stability during heavy machining operations
- Saw frame features manual feed for sensitive workpiece characteristics
- Hardened, polished helical gear with large bronze drive wheel for long service life
- Quiet operation, short machining times and easy handling ensure increased productivity
- Powerful motor for continuous operation
- High-capacity coolant system is included
- Includes base
- 1 saw blade
- coolant system
- base
- pressure gauge for saw blade tension
- hydraulic cylinder for saw frame
- inverter for infinitely variable saw blade speed
- hydraulic tool clamping
- operator manual
